Product Summary
The TMS320F2808PZA is a member of the TMS320C28XTM DSP generation, is highly integrated, high-performance solutions for demanding control applications. Its package is thin quad flatpack.
Parametrics
Absolute maximum ratings: (1)Supply voltage range, VDDIO, VDD3VFL (with respect to VSS): - 0.3 V to 4.6 V; (2)Supply voltage range, VDDA2, VDDAIO (with respect to VSSA): - 0.3 V to 4.6 V; (3)Supply voltage range, VDD (with respect to VSS): - 0.3 V to 2.5 V; (4)Supply voltage range, VDD1A18, VDD2A18 (with respect to VSSA): - 0.3 V to 2.5 V; (5)Supply voltage range, VSSA2, VSSAIO, VSS1AGND, VSS2AGND (with respect to VSS): - 0.3 V to 0.3 V; (6)Input voltage range, VIN: - 0.3 V to 4.6 V; (7)Output voltage range, VO: - 0.3 V to 4.6 V; (8)Input clamp current, IIK (VIN < 0 or VIN > VDDIO): ± 20 mA; (9)Output clamp current, IOK (VO < 0 or VO > VDDIO): ± 20 mA; (10)Operating ambient temperature ranges: TA: A version (GGM, PZ)(4):- 40℃ to 85℃; TA: S version (GGM, PZ): - 40℃ to 125℃; TA: Q version ( PZ)(4): - 40℃ to 125℃; (11)Junction temperature range, Tj: - 40℃ to 150℃; (12)Storage temperature range, Tstg: - 65℃ to 150℃.
Features
Features: (1)High-Performance Static CMOS Technology; (2)JTAG Boundary Scan Support; (3)On-Chip Memory; (4)Boot ROM (4K x 16); (5)Clock and System Control; (6)Any GPIO A Pin Can Be Connected to One of the Three External Core Interrupts; (7)Peripheral Interrupt Expansion (PIE) Block That Supports All 43 Peripheral Interrupts; (8)128-Bit Security Key/Lock; (9)Enhanced Control Peripherals; (10)Three 32-Bit CPU Timers; (11)Serial Port Peripherals; (12)12-Bit ADC, 16 Channels; (13)Low-Power Modes and Power Savings.
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TMS320F2808PZA |
Texas Instruments |
Digital Signal Processors & Controllers (DSP, DSC) 32-Bit Digital Sig Controller w/Flash |
Data Sheet |
|
|
|||||||||||||
