Product Summary

The MM5451YV is produced using planar DMOS technology. And this Power MOSFET is well suited for Battery switch, Load switch, Motor controller and other small signal switches.

Parametrics

MM5451YV absolute maximum ratings: (1)VDSS, Drain to Source Voltage: 60 V; ID, Continuous Drain Current(@TA = 25℃): 200 mA; IDM Drain Current Pulsed: 500 mA; (2)VGS, Gate to Source Voltage: ±20 V; (3)PD, Total Power Dissipation Single Operation (TA=25℃): 0.4 W; Total Power Dissipation Single Operation (TA=70℃): 3.2 mW; (4)TSTG, TJ Operating Junction Temperature & Storage Temperature: - 55 ~ 150 ℃; (5)TL, Maximum Lead Temperature for soldering purpose, 1/8 from Case for 10 seconds: 300℃.

Features

MM5451YV features: (1)RDS(on) (Max 5)@VGS=10V; RDS(on) (Max 5.3)@VGS=4.5V; (2)Gate Charge (Typical 0.5nC); (3)Maximum Junction Temperature Range (150℃).

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
MM5451YV
MM5451YV


IC LED DISPLAY DRIVER 44-PLCC

Data Sheet

0-1: $2.27
1-25: $1.81
25-100: $1.41
100-250: $1.34
250-500: $1.31
MM5451YV TR
MM5451YV TR


IC DRIVER DISPLAY LED 44PLCC

Data Sheet

0-1: $2.27
1-25: $1.81
25-100: $1.41
100-250: $1.34
