Product Summary
The MPC8321EVRAFDC is a cost-effective, highly integrated communications processor that addresses the requirements of several networking applications, including ADSL SOHO and residential gateways, modem/routers, industrial control, and test and measurement applications. The MPC8321EVRAFDC extends current PowerQUICC offerings, adding higher CPU performance, additional functionality, and faster interfaces, while addressing the requirements related to time-to-market, price, power consumption, and board real estate.
Parametrics
MPC8321EVRAFDC absolute maxing ratings: (1)Core supply voltage VDD: –0.3 to 1.26 V; (2)PLL supply voltage AVDDn: –0.3 to 1.26 V; (3)DDR1 and DDR2 DRAM I/O voltage GVDD: –0.3 to 2.75 V/–0.3 to 1.98 V; (4)PCI, local bus, DUART, system control and power management, I2C, SPI, MII, RMII, MII management, and JTAG I/O voltage OVDD: –0.3 to 3.6 V; (5)Input voltage DDR1/DDR2 DRAM signals MVIN: –0.3 to (GVDD + 0.3) V; (6)Storage temperature range TSTG: –55 to 150 ℃.
Features
MPC8321EVRAFDC features: (1)Single platform architecture supports the convergence of IP packet networks and ATM networks; (2)DDR1/DDR2 memory controller-one 32-bit interface at up to 266 MHz supporting both DDR1 and DDR2; (3)An e300c2 core built on Power Architecture technology with 16-Kbyte instruction and data caches, and dual integer units.
Diagrams
Image | Part No | Mfg | Description | Pricing (USD) |
Quantity | |||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
MPC8321EVRAFDC |
Freescale Semiconductor |
Microprocessors (MPU) 8321 NOPB PBGA W/ ENCR |
Data Sheet |
|
|
|||||||||||||
