Product Summary
The CY62128EV30LL-45ZAXI is a high performance CMOS static RAM module organized as 128K words by 8 bits. This device features advanced circuit design to provide ultra low active current. This is ideal for providing More Battery Life (MoBL) in portable applications such as cellular telephones.
Parametrics
CY62128EV30LL-45ZAXI absolute maximum ratings: (1)Storage Temperature: –65℃ to +150℃; (2)Ambient Temperature with Power Applied: 55℃ to +125℃; (3)Supply Voltage to Ground Potential: –0.3V to VCC(max) + 0.3V; (4)DC Voltage Applied to Outputs; (5)in High-Z State: –0.3V to VCC(max) + 0.3V; (6)DC Input Voltage: –0.3V to VCC(max) + 0.3V; (7)Output Current into Outputs: 20 mA; (8)Static Discharge Voltage: > 2001V; (9)Latch up Current: > 200 mA.
Features
CY62128EV30LL-45ZAXI features: (1)Very high speed: 45 ns; (2)Wide voltage range: 2.20V ?3.60V; (3)Pin compatible with CY62128DV30; (4)Easy memory expansion with CE1, CE2 and OE features; (5)Automatic power down when deselected; (6)CMOS for optimum speed and power; (7)Offered in Pb-free 32-pin SOIC, 32-pin TSOP I, and 32-pin STSOP packages.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 CY62128EV30LL-45ZAXI |
Cypress Semiconductor |
SRAM 1M MOBL ULTRA LO PWR HI SPD IND |
Data Sheet |
|
|
||||||||||||
|
CY62128EV30LL-45ZAXIT |
Cypress Semiconductor |
SRAM 1M MOBL ULTRA LO PWR HI SPD IND |
Data Sheet |
|
|
||||||||||||
