TC58NVG0S3AFT

static registers, TSOP, Toshiba, －0.6 to 4.6 V, TC58NVG0S3AFT

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.60~3.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $2.60~3.00

PartNumber:: TC58NVG0S3AFT

Brand:: Toshiba Semiconductor - Toshiba | Pack: TSOP | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. cathy's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-12-13

From Other Seller

Part Number:TC58NVG0S3AFT
US $2.60 - 3.00
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The TC58NVG0S3AFT is a 1 gbit (128m × 8 bits) cmos nand eeprom organized as (2048 + 64) bytes × 64 pages × 1024 blocks. The TC58NVG0S3AFT has a 2112-byte static registers which allow program and read data to be transferred between the register and the memory cell array in 2112-byte increments. The Erase operation is implemented in a single block unit (128 Kbytes + 4 Kbytes: 2112 bytes × 64 pages). The TC58NVG0S3AFT is a serial-type memory device which utilizes the I/O pins for both address and data input/output as well as for command inputs. The Erase and Program operations are automatically executed making the device most suitable for applications such as solid-state file storage, voice recording, image file memory for still cameras and other systems which require high-density non-volatile memory data storage.

Parametrics

TC58NVG0S3AFT absolute maximum ratings: (1)VCC Power Supply Voltage: －0.6 to 4.6 V; (2)VIN Input Voltage: －0.6 to 4.6 V; (3)VI/O Input /Output Voltage: －0.6 V to VCC + 0.3 V (≤ 4.6 V) V; (4)PD Power Dissipation: 0.3 W; (5)TSOLDER Soldering Temperature (10 s): 260 °C; (6)TSTG Storage Temperature: －55 to 150 °C; (7)TOPR Operating Temperature: 0 to 70 °C.

Features

TC58NVG0S3AFT features: (1) Modes: Read, Reset, Auto Page Program, Auto Block Erase, Status Read; (2) Mode control: Serial input/output, Command control; (3) Powersupply VCC = 2.7 V to 3.6 V; (4) Program/Erase Cycles 1E5 Cycles (With ECC); (5) Package TSOPI48-P-1220-0.50 (Weight: 0.53 g typ.).
