S29GL032N90FFI

Flash memory, BGA, SPANSION, –0.5 V to +12.5 V, 200 mA, S29GL032N90FFI

Rated 5 Rating 5 | reviews | Write a review

Price:: US $1.25~1.65 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $1.25~1.65

PartNumber:: S29GL032N90FFI

Brand:: SPANSION - spansion | Pack: BGA | D/C: 10+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. cathy's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-09-07

From Other Seller

Part Number:S29GL032N90FFI
US $1.25 - 1.65
2DI75D-050A

US $16.00 - 30.00 / Piece
(0) Remove
QM75DY-H

US $16.00 - 30.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The S29GL032N90FFI is a 3.0-Volt single-power Flash memory manufactured using 110 nm MirrorBit technology. The device is a 64-Mb device organized as 4,194,304 words or 8,388,608 bytes. Depending on the model number, the S29GL032N90FFIhas 16-bit wide data bus only, or a 16-bit wide data bus that can also function as an 8-bit wide data bus by using the BYTE# input. The S29GL032N90FFIcan be programmed either in the host system or in standard EPROM programmers.

Parametrics

S29GL032N90FFI absolute maximum ratings: (1)Storage Temperature, Plastic Packages: –65 to +150℃; (2)Ambient Temperature with Power Applied: –65 to +125℃; (3)Voltage with Respect to Ground, VCC: –0.5 V to +4.0 V; (4)A9, OE#, ACC and RESET#: –0.5 V to +12.5 V; (5)All other pins: –0.5 V to VCC+0.5 V; (6)Output Short Circuit Current: 200 mA.

Features

S29GL032N90FFI features: (1)Single power supply operation; (2)Manufactured on 110 nm MirrorBit process technology; (3)Secured Silicon Sector region; (4)Flexible sector architecture; (5)Enhanced VersatileI/O Control; (6)Compatibility with JEDEC standards; (7)100,000 erase cycles typical per sector; (8)20-year data retention typical.
