Product Summary

The AT29BV040A-20TU is a 3-volt-only in-system Flash Programmable and Erasable Read Only Memory (PEROM). Its 4 megabits of memory is organized as 524,288 words by 8 bits. Manufactured with Atmel’s advanced nonvolatile CMOS EEPROM technology, the device AT29BV040A-20TU offers access times to 200 ns, and a low 54 mW power dissipation. When the device AT29BV040A-20TU is deselected, the CMOS standby current is less than 50 μA. The device endurance is such that any sector can be written to in excess of 10,000 times. The programming algorithm is compatible with other devices in Atmel’s 2.7-volt-only Flash memories.

Parametrics

AT29BV040A-20TU absolute maximum ratings: (1)Temperature Under Bias: -55 to +125℃; (2)Storage Temperature: -65 to +150℃; (3)All Input Voltages (including NC Pins) with Respect to Ground: -0.6V to +6.25V; (4)All Output Voltages with Respect to Ground: -0.6V to VCC + 0.6V; (5)Voltage on A9 (including NC Pins) with Respect to Ground: -0.6V to +13.5V.

Features

AT29BV040A-20TU features: (1)Single Supply Voltage, Range 2.7V to 3.6V; (2)Single Supply for Read and Write; (3)Software Protected Programming; (4)Fast Read Access Time: 200 ns; (5)Low Power Dissipation: 15 mA Active Current; 50 μA CMOS Standby Current; (6)Sector Program Operation: Single Cycle Reprogram (Erase and Program); 2048 Sectors (256 Bytes/Sector); Internal Address and Data Latches for 256 Bytes; (7)Two 16K Bytes Boot Blocks with Lockout; (8)Fast Sector Program Cycle Time ?20 ms Max.; (9)Internal Program Control and Timer; (10)Minimum Endurance 10,000 Cycles; (11)CMOS and TTL Compatible Inputs and Outputs; (12)Green (Pb/Halide-free) Packaging Option.
